Flight Performance

In the words of Dquad Race Pilot Hugo Marco Lopez

The geometry of the frame is perfect to keep it light and clear of turbulence in the air. Thanks to the strong arm locking system and its high quality carbon fiber the frame feels rock solid in the air, it has a strong feeling in fast turns and makes it easier to keep your momentum during high speed cornering. The placement of the camera mount and the geometry of the frame help a lot to make fast and stable orbital turns, especially in ladder-style movements. Thanks to its efficient design the frame has the perfect combination of strength and lightweight to help you to take the shortest and closest lines in the track without effort. The overall stability provided by the frame in flight helps to find smooth lines, after getting confident with the feeling you will feel like the quad flies on rails.

After testing a lot of frames from several brands I've found that the Fixation is unique! Since the first flight I noticed how stable, solid and light it was! It has the most efficient design I have ever witnessed. The arm locking system is extremely light, strong and easy to set up! It is the lightest and strongest frame I have ever tried by far! I feel super confident with it in the air as I don't worry about breaking arms anymore. It also has a light carbon fiber camera mount that provides perfect protection and clear image feed, I just love it! If that isn't enough for you, the frame comes with a sticky battery pad that keeps it insanely strong attached to the frame to make sure it doesn't move in a crash.


Hugo Marco Lopez accomplishments 2022

1st Spanish Drone Championship

2nd I Ceramica drone race

3rd National Open Valladolid

1st GaelicGP Santiago

2nd FAI World Cup Tenerife

2nd Ceramica night race



Specifications

  • Armattan high-heat pressed 3k twill weave carbon fiber.

  • True X-135mm

  • Frame weight-58 grams

  • Arm Thickness-5x9mm

  • Top Plate-2.5mm

  • Hdzero Top Plate-2mm

  • Main Plate-3mm

  • Bottom Plate-3mm

  • Camera Plates-2mm

  • Deck Height-25mm

  • Stack Height-25mm

  • Supported Stacks-20x20 and 30x30

  • Prop Size-5.1 inch

Highlights

  • Milled main and bottom plate

  • Very stiff, strong easy to tune

  • includes high grade titanium hardware including motor bolts

  • includes 1.2 gram super sticky Lite Grip lipo pad cut to the dimensions of the bottom plate.

  • Includes the standard race top plate and Hdzero top plate.

  • includes main plate front bumper


Hugo Marco Lopez-1st place FIA Spain World cup Spanish Championship-Fixation

Innovation

Milled arm and lipo strap channels

Countersunk bottom plate and main plate with press nuts inserted.

The arms lock securely into the milled arm channels-no wiggle plate needed!

Package Includes

  • 4 x 5.1 inch arms

  • 1 x Bottom plate

  • 1 x Main plate

  • 1 x Race top plate

  • 1 x Hdzero top plate

  • 2 x Camera plates

  • 4 x M3x25x5mm aluminum standoffs

  • 4 x M3x10mm titanium CS bolts

  • 4 x M3x14mm titanium CS bolts

  • 4 x M3x6mm titanium BH bolts

  • 4 x M3x25mm titanium FC bolts

  • 12 x M3x8mm titanium motor bolts

  • 4 x Nylon FC nuts

  • 1 x Dquad lipo strap

  • 1 x Lite grip lipo pad

  • 1 x Main plate front bumper

  • 1 x Fixation sticker


Fly the Fixation on Liftoff Drone Simulator
