Addiction 5.1” V4
Our Addiction frame is back! And back with an exciting new V4 update! The Addiction is a middle-weight frame which offers incredible strength. Three years of continuously improving the design has led us to the point where we are very confident that this frame is one of the strongest out there while still being sub 100 grams. The combination of carbon fiber and high grade aluminum and the fact that you can easily swap arms makes sure you get as much flight time (and crashes) as possible. No corners were cut with the design of this frame which results in a high level of detail where every millimeter of the frame has a function.
Key features
Armattan high-heat pressed 3k twill weave carbon fiber
7075 aircraft grade aluminum
Good airflow
Lipo strap passes through the middle of the frame
Countersunk bolts and press nuts
Obsession bracket compatible
Integrated xt60 mount
5.1”
Slotted camera mount hole for slight adjustment forward or back
HD compatible-DJI 03 with adapter kit, Hdzero, Walksnail
Dquad Pilot Carson Grier’s Addiction flight footage video Montage.
Specifications
204mm size 5.1” X frame
Prop size-5-5.1”
Supports 30x30 and 20x20 FC stacks. Stack bolt sizes= M3
Frame weight-94 grams
Supported cameras-19mm micros, DJI 03 with 03 adapter kit
HD compatible-DJI 03, Hdzero, Walksnail and Vista
Arms-6mm
Top plate-2mm
Bottom plate-2mm
Main plate-2mm
Camera cage-7075 aluminum
Rear bracket-7075 aluminum
Fly the Addiction on Liftoff Drone Simulator
Package Includes
4x 5.1” arms 6mm thick, 8mm wide (10mm at critical spots)
1x 2mm bottom plate
1x 2mm middle plate with press nuts installed
1x 2mm top plate
2x 7075 front bracket
1x 7075 rear bracket
6x M3x6 button head bolts
4x M3 x4 button head bolts
12x M3x10 countersunk bolts
4x M3x19mm black cage standoffs
4x M3x25mm FC bolts
1x SMA VTX tpu mount
1x Xt60 connector
1x Lipo pad
1x Dquad lipo strap
1x Addiction sticker
Optional DJI 03 kit
1x Full top plate
3x M3 20mm standoffs
1x 03 air unit mount
